Double-Cylinder Hydraulic Shear with 360° Rotation and Alloy Blade for Excavator Attachment

Product Categories
Yantai Dopro Industry Technology Co, Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Double-Cylinder Hydraulic Shear with 360° Rotation and Alloy Blade for Excavator Attachment

  • 1
  • 2

Brand Name : Dopro

Model Number : DPAC4500

Certification : ISO CE

Place of Origin : CHINA

MOQ : 1

Price : 100-600

Supply Ability : 6000 Pcs Per Month

Delivery Time : 3-7 Working Days

Packaging Details : Export Wooden Cases /Pallet

Product name : concrete pulverizer,hydraulic pulverizer,Excavator Attachement(Pulverizer_One Cylinder Type)

Warranty : 12 Months

Color : Requirement,Customer Required

Material : Q345B,NM360/400,HARDOX450/500

Application : Excavator,framework etc.,framework and pylons

After-sales service provided : Online support,Video technical support

Type : Hydraulic,Pulverizer,Heavy duty,Mine,Standard

Weight : 890kgs-4200kgs

Name : Hydraulic Jaw Pulverizer,hydraulic demolition shear

Suitable excavator : 17-24ton

Packing : Pallet with wrapping or Customization,Wooden Pallet or Customized

Jaw opening : 0-890MM

OEM : available,YES

Part name : Excavator pulverizer and shear

Contact Now

DH300 PC290 320D Hydraulic Shear, Hydraulic Demolition Shears OEM
B250 DH300 PC290 320D Hydraulic sharp Shear Hydraulic Demolition Shear for 5-35 Tons Excavator Attachment
The double-cylinder hydraulic shear represents an advanced improvement over existing double-cylinder hydraulic pliers. Developed specifically for steel shearing applications with added alloy blades, this hydraulic demolition shear delivers significantly higher cutting force compared to similar olecranon shears. Engineered to handle the demanding requirements of recycling super-hard steel plates, steel bars, and other high-hardness metals.
Applications
Widely used in steel scrap processing and scrap car recycling facilities.
Main Features
  • Material: ThyssenKrupp XAR steel - durable construction, high machining precision, and exceptional breaking capacity
  • 360° rotation function available
The rotation system incorporates an increased number of fixing screws and gear bearings, delivering more stable performance and stronger power transmission.
New one-click adjustment system simplifies split problem resolution, eliminating previously cumbersome adjustment steps.
Complete scissor arm upgrade with reinforced ribs to prevent metal fatigue cracking risks.
Customized five-way sealing cylinder design minimizes oil leakage risks and extends service life.
Double-Cylinder Hydraulic Shear with 360° Rotation and Alloy Blade for Excavator Attachment
Technical Specifications
DESCRIPTION UNT DPAP1600 DPAP2000 DPAP3000 DPAP4500
Applicable Excavator ton 14~20 18~26 26~32 38~48
Applicable Excavator lbs 30,864~44,092 39,683~57,320 57,320~70,547 83,775~105,821
Operating Weight kg/lbs 1,250/2,755 1,800/3,968 2,350/5,180 3,450/7,605
Overall Length(L) mm/inch 1,580/62.2 1,806/71.1 1,990/78.3 2,336/91.9
Jaw Opening mm/inch 800/31.4 980/38.5 1,100/43.3 1,300/51.1
Force at Mid ton/lbs 70/154,323 120/264,554 195/429,901 270/595,248
Operating Pressure bar/psi 280/4,061 300/4,351 320/4,641 320/4,641
Setting Pressure bar/psi
Rotation Type Fixed
